China VI Sinotruk HOWO foam fire truck with a combined 16 m³ of extinguishing agent: a 12 m³ carbon-steel water tank (internally anti-corrosion treated) and a 4 m³ 304-stainless-steel foam tank, on a 6×4 rear-tandem chassis with wheelbase 4,300+1,400 mm and overall dimensions 9,680×2,550×3,620 mm.
With the 460 hp Man-technology engine, full-power sandwich PTO and CB10/60 pump, it delivers water and foam solution for Class A and B fires — built for government fire brigades, urban main-attack duties, chemical plants, power companies and substations.
Product overview
Announcement Parameters
- Vehicle Model: CLW5280GXFPM120/HW
- Vehicle Type: Sinotruk HOWO foam fire truck (heavy, China VI)
- Drive Type: 6×4 (rear tandem)
- GVWR: 28,000 kg
- Curb Weight: approx. 11,000 kg (reference; per official announcement)
- Rated Load Capacity: approx. 16,800 kg (reference; per official announcement)
- Tank Volume: Water 12,000 L (12 t) + foam 4,000 L (4 t); carbon steel / stainless steel, rust- and leak-proof
- Emission Standard: China VI
Chassis Configuration
- Chassis Model: Sinotruk HOWO ZZ1327 (China VI, rear tandem)
- Cab: Double-row cab seating 2+4 (6 persons)
- Engine: Sinotruk MC13.46-60, 460 hp China VI diesel engine (Man technology)
- Wheelbase / Tires / Standard: 4,300+1,400 mm wheelbase; 12.00R20 tires; factory A/C, power windows, central locking, ABS, power steering
Fire-Fighting Configuration
- Tank & Pump Compartment: Separate water and foam tanks; carbon-steel water tank with internal anti-corrosion treatment, foam tank in 304 stainless steel; anti-wave baffles; rear pump compartment with CB10/60 pump behind aluminum roller-shutter doors
- Pump & Performance: CB10/60 atmospheric fire pump rated at 60 L/s at 1.0 MPa; delivers water or foam solution for Class A and B fires; roof Weiste PS50 monitor with range ≥68 m; supports fast tank refill and forest-fire relay water supply
- Equipment Lockers: Large side lockers with steel framework, concealed lap joints, patterned aluminum lining, secure tie-downs and low-noise sealed aluminum roller-shutter doors; interior lighting for night use
- Operation & Safety: Monitor controls, level gauge, pressure gauge, emergency lighting, reversing camera, extinguisher and grounding device; roof fire warning lamp and reflective markings meeting GB7956-2014; suitable for government fire rescue teams, urban main-attack duty, chemical enterprises, power plants and substations
- Optional Extras: Communications/command system, remote monitoring, various fire couplings and nozzles, aluminum guardrails, forcible-entry tool set
